digital clock using arduino

 digital clock






digital clock using arduino

digital clock using arduino

digital clock using arduino


programming code


#include <Arduino.h>

#include <Wire.h>

#include "RTClib.h"

#include <TM1637Display.h>



#define CLK 2 // TM1637 PIN to Arduino

#define DIO 3

RTC_DS3231 RTC;

TM1637Display display(CLK, DIO);

char daysOfTheWeek[7][12] = {"Sunday", "Monday", "Tuesday", "Wednesday", "Thursday", "Friday", "Saturday"};


int Button1=8; // Button SET

int Button2=7; // Button for +

int Button3=6; // Button for -


int hrs;

int mins;


int states =0;


unsigned long previousSecond = 0;

const long interval = 2;


uint8_t data[] = { 0x00, 0x00, 0x00, 0x00 };

const uint8_t SEG_DASH[] = {

 SEG_G,

 SEG_G,

 SEG_G,

 SEG_G

  };


void setup()

{




  pinMode(Button1,INPUT_PULLUP);

  pinMode(Button2,INPUT_PULLUP);

  pinMode(Button3,INPUT_PULLUP);

  int states=0;




#ifndef ESP8266

  while (!Serial); // for Leonardo/Micro/Zero

#endif


 // Serial.begin(9600);





  if (! RTC.begin()) {

   // Serial.println("Couldn't find RTC");

    while (1);

  }


  if (RTC.lostPower()) {

    Serial.println("RTC lost power, lets set the time!");



    //rtc.adjust(DateTime(F(__DATE__), F(__TIME__)));




  }



}



void loop()


 display.setBrightness(0x0f);



  if(digitalRead(Button1)==LOW){

    delay(20);

     if(digitalRead(Button1)==LOW){

       states=states+1;

       delay(100);

     }

  }



  if (states==0)

    {

     DisplayCurrentTime(); // Show Current time


    }

  if (states==1)

    {

    SetHour();

    }

  if (states==2)

    {

    SetMinute();

    }

  if (states==3)

    {

    SetTime();

    states=0;

    }



}


void DisplayCurrentTime ()

{

  DateTime now = RTC.now();



  uint8_t hour12 = now.hour()%12 == 0? 12 : now.hour()%12;

  String st = String(hour12,DEC);

  char dateBuffer[12];

  sprintf(dateBuffer,"%02u%02u",hour12,now.minute());



  String myTime=String(dateBuffer);

  int myTimeInt=myTime.toInt();



  display.showNumberDec(myTimeInt,false,4,0);

  unsigned long currentSecond = now.second();

  if (currentSecond - previousSecond >= interval)

  {

        previousSecond = currentSecond;

        display.showNumberDecEx(myTimeInt, (0x80 >> 1),false,4,0);

        delay(1000);

  }





  hrs=now.hour();

  mins=now.minute();



}


void SetHour()

{



 display.setSegments(data);



  if(digitalRead(Button2)==LOW)

  {

    if(hrs==23)

    {

      hrs=0;

    }

    else

    {

      hrs=hrs+1;

      delay(100);

    }

  }

   if(digitalRead(Button3)==LOW)

  {

    if(hrs==0)

    {

      hrs=23;

    }

    else

    {

      hrs=hrs-1;

      delay(100);

    }

  }

display.showNumberDec(hrs, false, 2, 2);

}


void SetMinute()

{

  display.setSegments(data);



  if(digitalRead(Button2)==LOW)

  {

    if (mins==59)

    {

      mins=0;

    }

    else

    {

      mins=mins+1;

      delay(100);

    }

  }

   if(digitalRead(Button3)==LOW)

  {

    if (mins==0)

    {

      mins=59;

    }

    else

    {

      mins=mins-1;

      delay(100);

    }

  }

display.showNumberDec(mins, false, 2, 2);

}



void SetTime()

{

  display.setSegments(SEG_DASH);

  RTC.adjust(DateTime(2022,1,1,hrs,mins,0));

  delay(1000);

}
